BEB-0864TN-1
    发布时间: 2019-04-02 13:04

Suitable for Most 37-70 inch LED LCD Curved Screen Swivel TV Mounts

BEB-0864TN-1


Feature:

1) Fits most 37"-70" flat panel TV

2) VESA compliance: 600x400mm

3) Material : SPCC with coating finished

4) Weight capacity : 110lbs (50kg)

5) Tiltable angle+20/-20 degrees

6) Swivel angle: 120 degrees

7) Distance to wall: 59~473mm

8) Color : black / silver
9) Mounting hardware included

10) Easy to install

11) User Manual included

12) Universal tv mounts

From:

Model BEB-0864TN-1 Remark
Brand Bestever
Color black or sliver color
Packing Bestever color box package,Plain white box
Material SPCC with coating finished
Suitable TV Size 37"~70"
Max Load Weight 110lbs(50kg)
Max VESA Pattern 600X400mm
Distance to wall 59~473mm
Tiltable angle -20~+20 degree

TV Wall Mount LCD/LED/TV Articulated Bracket

Fits most 40"- 70" curved & flat panel TVs

This TV wall mount bracket is a dual-arm full-motion wall mount for most curved & flat panel TVs up to 70" and with a 50kg weight loading. This mount extends out 510mm from wall and allows TVs to turn ±60° left or right. Full movement motion allows maximum flexibility — tilt and swivel your TV for easy viewing. Post-installation level adjustment allows the TV to “roll” up to 3° clockwise and anticlockwise to ensure it is perfectly level. Integrated cable management system keeps cables organised and protected. Wide wall plate fits Australian 450-600mm stud installation.

FEATURES

  • Freely tilting allows easy TV angle adjustment freely tilting allows easy TV angle adjustment
  • Swiveling arm offer maximum viewing flexibility swiveling arm offer maximum viewing flexibility
  • Built-in level adjustment ensures perfect positioning built-in level adjustment ensures perfect positioning
  • Cable management system helps keep cables concealed and organised
  • Strength has been tested for a minimum of three times its stated load capacity
  • Allowances for Australian 450 / 600mm stud wallspacing
  • Mounting Profile: 64-510mm
  • Swivel left & right: ±60°with -20°/+5°vertical tilt
  • Maximum loading capacity: 50kg
  • Level adjustment: ±3°
  • Sturdy wishbone design
  • Decorative cover presents elegant finishVESA:600x400
